05CuPCrNi Corten Material Feature
05CuPCrNi resistant to atmospheric corrosion of steel, which contains phosphorus, copper, chromium, nickel, molybdenum, niobium, vanadium, titanium and other chemical components and oxygen in the air chemical reaction, 05CuPCrNi surface to form a dense oxide protective film, 05CuPCrNi has a good anti-rust protection and corrosion resistance. 05CuPCrNi for the manufacture of steel structures exposed to the atmosphere and the external support of large buildings, such as train tracks, containers, H-beam, I-beam, channel, angle steel, etc.
05CuPCrNi Chemical properties(%):
Grade |
The Element Max (%) |
||||
05CuPCrNi |
C |
Si |
Mn |
P |
S |
≤0.090 |
0.25-0.50 |
0.20-0.50 |
0.06-0.12 |
≤0.020 |
|
Cr |
Cu |
Ni |
- |
- |
|
0.30-1.25 |
0.25-0.50 |
0.12-0.65 |
- |
- |
05CuPCrNi Physical properties:
Grade |
Thickness |
Yield |
Tensile |
Elongation |
05CuPCrNi |
mm |
Min Mpa |
Mpa |
Min % |
≤4 |
310 |
440 |
26 |
05CuPCrNi Size range:
Thickness: 2mm to 200mm,
Width: 1000mm to 4050mm,
Length: 2000mm to 15000mm
Feature of 05CuPCrNi:
Excellent weather resistance
Long service life
Environmental friendly
Good performance of high mirror polishing
Anti-acid, anti-rust after heat- treatment
Good corrosion resistance
Resistance for erosive attack
Low deformation rate
Good stability
