1.0045 s355jr steel Plate Processing
S355JR is a low carbon, high tensile strength structural steel which can be readily welded to other weldable steel. With its low carbon equivalent, it possesses good cold-forming properties. 1.0045 s355jr steel Plate is mainly used in Structural application in freight cars, transmission towers, dump trucks, cranes, trailers and so on.
S355JR Chemical Composition(max%):
|
Grade |
C% |
Si% |
Mn% |
P% |
S% |
N% |
Cu% |
|
S355JR |
0.27 |
0.60 |
1.70 |
0.035 |
0.035 |
0.012 |
0.60 |
S355JR Mechanical Properties.
|
Grade |
Thickness(mm) |
MinYield(Mpa) |
Tensile(Mpa) |
Elongation(%) |
MinImpactEnergy |
|
|
S355JR |
8mm-100mm |
315Mpa-355Mpa |
450-630Mpa |
18-20% |
20 |
27J |
|
101mm-200mm |
285-295Mpa |
450-600Mpa |
18% |
20 |
27J |
|
|
201mm-400mm |
275Mpa |
- |
17% |
20 |
27J |
|
|
Theminimpactenergyislongitudinalenergy |
||||||
Equivalent grades of grade S355JR (1.0045)
|
USA |
Germany |
Japan |
France |
England |
Canada |
European old |
Italy |
Belgium |
Spain |
China |
Sweden |
Inter |
Portugal |
India |
|||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1.0045 s355jr steel Plate Welding performance
Our production completely according to the 1.0045 standards to meet the 1.0045 Welding performance, can also according to the customer request, to meet the requirements of customers of 1.0045 Welding performance.
1.0045 s355jr steel Plate Delivery Condition:
Smelting: EAF+LF+VD (+ESR)
Making: Hot rolled, Cold rolled, Forged, Cold Drawn
Heat Treatment: Untreated, Annealing, N+T, Q+T
Surface: Black, Peeled, Turned, Milled, Grinded, Polished
We have our own processing factory and the pre- treatment factory, Surface pretreatment line technical parameters on steel plates and profile steel. And we can also make the customers enjoy our other pre-treatment services, like cutting, welding, drilling holes, galvanizing by the lowest cost price. We are a professional1.0045 s355jr steel Plate exporter and Stockist in china. Any need in 1.0045 s355jr, please feel free to contact us by email or calling to us by email [email protected]
