1.0332 Steel Material Equivalent Grade

Posted:2016-08-25 04:54:30

1.0332 Steel Material Equivalent Grade

1.0332 Steel is one of a series of grades produced to display excellent direct cold forming characteristics and high strength levels. 1.0332 Steel is particularly useful in applications requiring edging and complex, narrow shapes but it is also often specified for projects incorporating non structural press work.

Chemical composition % of grade DD11 (1.0332): EN 10111-2008

C

Mn

P

S

max 0.12

max 0.6

max 0.045

max 0.045

Mechanical properties of grade DD11 (1.0332)

Rm- Tensile strength (MPa)

440


Nominal thickness (mm):

1 - 2

2 - 11

ReH- Minimum yield strength (MPa)

170-360

170-340


Nominal thickness (mm):

1 - 1.5

1.5 - 2

2 - 3

A- Min. elongation Lo = 80 mm (%)

22

23

24


Nominal thickness (mm):

3 - 11

A- Min. elongation Lo = 5,65 √ So (%)

28

Equivalent grades of grade DD11 (1.0332)

USA
-

Germany
DIN,WNr

Japan
JIS

France
AFNOR

England
BS

Italy
UNI

Spain
UNE

Poland
PN

Czechia
CSN

Russia
GOST

Inter
ISO

A621CQ

CS

StW22

SPHD

1C

HR3

FeP11

AP11

08J

11331

15kp

HR2

1.0332 Steel Welding

1.0332 Steel using most common conventional methods, this steel can be welded with ease, without the need for preheating beforehand.

1.0332 Steel Forming

1.0332 Steel especially suited to bending and deep drawing, this grade of steel is noted for its outstanding formability.

We are a trusted and reliable brand for our high quality and good manufacturing of 1.0332 Steel . Our company has been a manufacturer and exporter of 1.0332 Steel for decades, and has been sold all over the world with favorable price. As a responsible enterprise, we always stick to be your satisfying partner.
