1.0425 Steel Equivalent Grades
1.0425 Steel is pressure-vessel steel grade. Its tensile strength is between 410 and max. 530 N/mm².This grade is weldable. 1.0425 Steel is being used petroleum, chemical, power plants, boilers and other industries.
Chemical composition % of grade P265GH (1.0425): EN 10028-2-2003
C(％): ≤0.20
Si(％): ≤0.40
Mn(％): 0.50～1.40
P(％)≤: 0.030
S(％)≤: 0.025
Cr(％): ≤0.30
Mo(％): ≤0.08
Ni(％): ≤0.30
Other(％): Cu≤0.30①；Al≤0.020；Nb≤0.01；Ti≤0.03；V≤0.02
Mechanical properties of grade P265GH (1.0425)
|
Nominal thickness (mm): |
to 100 |
100 - 150 |
150 - 250 |
|
Rm- Tensile strength (MPa) (+N) |
410-530 |
400-530 |
390-530 |
|
Nominal thickness (mm): |
to 16 |
16 - 40 |
40 - 60 |
60 - 100 |
100 - 150 |
150 - 250 |
|
ReH- Minimum yield strength (MPa) (+N) |
265 |
255 |
245 |
215 |
200 |
185 |
|
KV- Impact energy (J) transverse, (+N) |
-20° |
0° |
+20° |
|
KV- Impact energy (J) longitud., |
-10° |
0° |
+20° |
USA - |
Germany |
Japan |
France |
England |
Italy |
Spain |
Sweden |
Poland |
Czechia |
Austria |
Russia |
Inter |
||||||||||||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Shanghai Katalor Enterprises Co., Ltd is a big complex combined steel stockist whose business related with trade, processing, storage and transportation. we are specialized in supplying1.0425 Steel. We have the good quality and advanced equipment, our products meet the state standard, and also available for customers' requirement. If you have any need of1.0425 Steel, please do not hesitate to contact us by email [email protected], we can do our best to help you!
