410 stainless steel Features
410 stainless steel is in accordance with the United States ASTM standards to produce stainless steel grades, the equivalent of China 1Cr13 stainless steel, S41000 (US AISI, ASTM). Carbon steel 0.15%, chromium 13%, 410 stainless steel: has good corrosion resistance, machinability, general purpose blade, valve class .410 stainless steel heat treatment: solution treatment (℃) 800-900 slow cooling or 750 fast cold.
410 stainless steel Chemical composition:
Composition |
C |
Si |
Mn |
P |
S |
Cr |
Standard |
0.15 |
1.00 |
1.00 |
0.04 |
0.030 |
11.5~13.5 |
General |
0.045 |
0.45 |
0.50 |
0.020 |
0.001 |
13. 0 |
410 stainless steel Physical parameters:
Density (g/cm) |
magnetic |
Specific heat 25℃(J/kg.℃) |
Thermal conductivity 100℃(W/m.℃) |
Thermal expansion coefficient 20~100℃(10/℃) |
7.70 |
|
460 |
24.9 |
9.9 |
410 stainless steel Mechanical properties:
Distinguish |
Ys (Mpa) |
Ts (Mpa) |
El (%) |
Hv |
Standard |
≥ 205 |
≥ 440 |
≥ 20 |
≤ 210 |
General |
260 |
470 |
30 |
145 |
410 stainless steel Features:
1) high strength;
2) Excellent machinability
3) hardening after heat treatment;
4) magnetic;
5) not suitable for harsh corrosive environment.
3, the scope of application
General blade, mechanical parts, 1 tableware (spoon, fork, knife, etc.).
