AH36 Shipbuilding Steel Plate Equivalent Material

Posted:2016-08-03 04:51:59

ABS AH36 has good toughness properties and higher strength. ABS AH36 Steel service the structural requirements of ships, barges, and other types of marineequipment.

ABS AH36 Chemical Composition:

ABS AH36 High Strength Chemical Composition
Grade	The Element Max (%)
Grade	C	Si	Mn	P	S	Al	N
ABS AH36	0.18	0.1-0.50	0.90-1.6	0.035	0.035	0.015
	Nb	V	Ti	Cu	Cr	Ni	Mo
	0.02-0.05	0.05-0.10	0.02	0.35	0.2	0.4	0.08

ABS AH36 Mechanical Property

Mechanical Property of AB/AH36 high strength
Grade	Thickness	Yield Strength	Tensile Strength	Elongation	Charpy V Notch Impact Test
Grade	Thickness	Yield Strength	Tensile Strength	Elongation	Degree	Value 1	Value 2
AB/AH36	mm	Min Mpa	Mpa	Min %	0	J	J
	t≤50	355	490-620	21%		24	34
	50＜t≤70	355	490-620	21%		27	41
	70＜t≤100	355	490-620	21%		34	50
Note: Value 1 is transverse impact test, Value 2 is longitudinal

ABS AH36 Equivalent

Equivalent steel grade of ABS AH36
DNV	GL	LR	BV	CCS	NK	KR	RINA
NV A36	GL-A36	LR/AH36	BV/AH36	CCS/A36	NK A36	KR A36	RI/A36

ABS AH36 Steel Specification

Thickness: 6mm to 240mm,
Width: 1400mm to 4020mm
Length: 3000mm to 12000mm.
We can supply any size based on the customer's requirement.

ABS AH36 Shipbuilding Steel Plate Service Features:

1. Accurate quotation, to reduce purchasing cost for you.
2. Timely communication, allowing you to monitor the entire production process and the progress
3. Superior quality, letting you go through the inspection of steel and supervise the quality of the finished products
4. Considerable transportation ,helping you to reduce the transportation cost and let you know the circumstance of the transport at any time.

Shanghai Katalor Enterprises Co., Ltd is a big complex combined steel stockist whose business related with trade, processing, storage and transportation. we are specialized in supplying ABS AH36 Steel Plate. Any need in. ABS AH36 Steel Plate, please fell free to contact us by email [email protected], we will try our best to help you.
