ASTM A572 Grade 60 Structural Steel Special Material

Posted:2016-10-11 04:36:19

ASTM A572 Grade 60 Structural Steel Special Material

A 572 Gr.60 steel plate is high strength low alloy columbium-vanadium structural steel grade.Compare with A572 Gr.50, A 572 Gr.60 steel has a more yield and tensile strength in project. If you want to more yield, you could choose A572 Gr.65 to use them in your projects.

Chemical composition % of the Product analysisof gradeA572 Grade60 .

A572 Grade 60 Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

V

Ni

Co

A572 Grade 60

0.26

0.4

1.35

0.04

0.05

0.06

0.015

0.05

Mechanical properties of gradeA572 Grade 60 Structural Steel

Grade

Thickness(mm)

Min Yield (Mpa)

Tensile(MPa)

Elongation(%)

A572 Grade 60

8mm-50mm

415Mpa

520Mpa

20%

50mm-200mm

415Mpa

520Mpa

24%

The min impact energy is longitudinal energy

ASTM A572 Grade 60 Other steel category:

Boiler steel plate

Marine steel

Corten steel plate

Stainless steel plate

HSLA steel plate

API Pipeline steel

Spring steel

Cold rolled steel

High Yield Steel

Section steel

A572 Grade 60 Structural Steel Specification:

Grade :A572 Grade 60
Thickness 8mm-200mm,
Width: 1500-4000mm,
Length: 3000-12000m
Besides, the size can be customized.
Standard: ASTM A572Standard Specification for High-Strength Low-Alloy Columbium-Vanadium Structural Steel
Approval By Third Party:ABS, DNV, GL, CCS, LR , RINA, KR, TUV, CE

As a very long history company, Shanghai Katalor Enterprise had enough experience about the quality, price for these goods in China Market. we are a professional A 572 Gr.60 steel plate stockist and supplier. We can supply different product type and grades of ASTM A572 Grade 60 Structural Steel . If you want to get the price, please do not hesitate tocontact us.
