ASTM A572-50 carbon-low alloy steel applications

Posted:2016-12-04 22:04:03

ASTM A572-50 is a carbon-low alloy steel with a low weight, high tensile strength and yield strength, good ductility and easy to weld. ASTM A572-50 contains a variety of alloying elements so that it has a better corrosion resistance. ASTM A572-50 can be used for bridge plate, gussets, floor, structural steel and other supporting materials.

ASTM A572-50 Physical properties:

Steel Type	High Strength/Low Alloy
ASTM Designation	A572 Grade 50
Common PGI Inventory	0.25” – 5.00” inquire for thicker plate
Minimum Yield Stress (ksi)	50
Average Tensile Strength (ksi)	65
Elongation at Breakage	18%
Approximate Hardness (Rc)	na
Approximate Hardness (Rb)	74
Brinell Hardness	135
Machinability	0.72

ASTM A572-50 Chemical composition:

% Carbon (C)	0.230
% Manganese (Mn)	1.35
% Niobium (Nb)	0.005-0.050
% Phosphorus (P)	0.040
% Silicon (Si)	0.150-0.400
% Sulfur (S)	0.050
% Vanadium (V)	0.010 – 0.050

ASTM A572-50 Application:
ASTM A572-50 is widely used in many applications, like: steel mills produce channel and heavy beams with Grade 50. It is commonly used in structural applications, heavy construction equipment, building structures, heavy duty anchoring systems, truck frames, poles, liners, conveyors, boom sections, structural steel shapes, and applications that require high strength per weight ratio.
