EN10025_5 S235J0W steel Mechanical Properties

Posted:2016-10-12 04:43:35

katalor steel

Under European standard EN10025_5 S235J0W steel is mainly used in hard weather. Atmospheric corrosion resistant steel, weathering steel from carbon steel to add a small amount of copper, nickel and other elements made of corrosion-resistant, high-quality steel with a tough, plastic casting, forming, welding, abrasion, heat, fatigue and other characteristics; at the same time, it resistant to rust, corrosion resistant components make life extension, thinning saving.

S235J0W Chemical composition:

C

Si

Mn

P

S

N

Cr

Cu

0.13

0.40

0.20-0.60

0.035

0.035

0.009

0.40-0.80

0.25-0.55

S235J0W Mechanical Properties:

Grade

Min. Yield Strength Mpa

Tensile Strength MPa

Impact

S235J0W

Nominal Thickness (mm)

Nominal Thickness (mm)

degree

J

Thick mm

≤16

>16
≤40

>40
≤63

>63
≤80

>80
≤100

>100
≤150

≤3

>3 ≤100

>100 ≤150

0

27

S235J0W

235

225

215

215

215

195

360-510

360-510

350-500

S235J0W applications:
For railway vehicles, bridges, towers and other exposed steel used in the atmosphere. S235J0W can also be used in the manufacture of containers, rolling stock, oil derrick, harbor construction, oil platforms and oil equipment chemical containers and other structures containing hydrogen sulfide corrosion medium.
