EN10028-2 265GH Pressure vessels steel equivalents

Posted:2016-09-28 04:53:34

EN10028-2 265GH Pressure vessels steel equivalents

P265GH material, which is ideally suited for elevated temperature service, is commonly found in the oil & gas, petrochemical and chemical industry. This European standard grade steel has replaced the BS1501 and DIN17155 specification.

P265GH Chemical composition

Element

% by mass

Element

% by mass

Carbon (C)

≤0.20

Silicon (Si)

≤0.40

Manganese (Mn)

0.80 to 1.40

Phosphorous (P) (max)

0.025

Sulphur (S) (max)

0.015

Aluminium (Al)

≤0.020

Nitrogen (N)

≤0.012

Chromium (Cr)

≤0.30

Copper (Cu)

≤0.30

Molybdenum (Mo)

≤0.08

Niobium (Nb)

≤0.020

Nickel (Ni)

≤0.30

Titanium (Ti) (max)

0.03

Vanadium (Vi)

≤0.02

P265GH Mechanical behavior

Grade

Type

Thickness
(mm)

Yield Strength
MPa (min)

Tensile Strength
MPa

Elongation
% (min)

Impact Energy
(KV J) (min)

-20°

+20°

P265GH

Normalized

≤16

265

410 to 530

22

27

34

40

16> to ≤40

255

410 to 530

22

27

34

40

40> to ≤60

245

410 to 530

22

27

34

40

60> to ≤100

215

410 to 530

22

27

34

40

100> to ≤150

200

400 to 530

22

27

34

40

150> to ≤250

185

390 to 530

22

27

34

40

P265GH equivalents:
There are a fair number of equivalents to P265GH with the most common being the ASTM/ASME A516 Gr 60 plates which it is often dual certified too. Generally the ASTM grade is more popular in the US and Asia with P265GH being more popular in Europe.
USA
ASTM A414E
ASTM A516 grade 60
ASME SA 516 grade 60
Germany
1.0425
DIN17155 HII
ST45.8
UK
BS 1501 151 -400
BS 1501 161 430
161 400
164 400
244 400
Japan
SG295
