How are the ASTM A240 301(S30100) Stainless Steel Material Properties Defined

Posted:2017-01-03 04:15:32

How are the ASTM A240 301(S30100) Stainless Steel Material Properties Defined

301L and 301LN are represented by other conventions. Grade 301L is represented by JIS G4305 and 301LN by EN10088-2 as grade 1.4318. Stainless steel grade 301 is usually supplied in the form of strips and wires.

301(S30100) Stainless Steel Chemistry Typical

Carbon: 0.15 max
Manganese: 2.00 max
Silicon: 1.00 max
Chromium: 16.00- 18.00
Nickel: 6.00- 8.00
Aluminum: 0.75 max
Phosphorus: 0.040 max
Sulphur: 0.030 max
Copper: 0.75 max
Nitrogen: 0.10 max
Iron: Balance

Mechanical properties of 301 grade stainless steel


Grade 301 Temper ASTM A666

Tensile Strength (MPa) min.

Yield Strength 0.2% Proof (MPa) min.

Elongation (% in 50mm) (thick.>0.76mm) min.

Bend Test (thickness > 1.27mm)

Bend Angle (°)

Factor

Annealed

758

276

60

-

-

1/16 Hard

620

310

40

180

1

1/8 Hard

690

380

40

180

1

1/4 Hard

862

514

25

90

2

1/2 Hard

1034

758

18

90

2

3/4 Hard

1205

930

12

90

3

Full Hard

1276

965

9

90

5

The typical applications of grade 301 stainless steels are listed below:

1, Making rail car structural components
2, Air frame sections
3, Highway trailer components
4, Automotive wheel covers
5, Wiper blade clips and holders
6, Stove element clips
7, Screen frames
8, Toaster springs
9, Curtain walls
