JIS G3106 SM570 Steel Plate Factory, Dimensional Characteristics of SM570 Steel

Posted:2016-11-21 03:58:42

Hussein Abdallah

SM570 steel grade is a low carbon, high strength structural steel with this low carbon equivalent, it process good cold forming property. SM570 steel is a material grade and designation defined in JIS G3106 standard. SM570 Steel is hot rolled steel for welded structure in the form of plates, sheets strips for architecture, engineering structures.

SM570 Chemical composition% of the Product analysisof grade

SM570 Chemical Composition

Grade

The Element Max (%)

C

Si

Mn

P

S

Cu (min)

SM570

0.18

0.55

1.70

0.035

0.035

-

SM570 Mechanical Property

Grade

SM570 Mechanical Property

Thickness

Yield

Tensile

Elongation

SM570

mm

Min Mpa

Mpa

Min%

t≦16

460

570-720

19

16<t≦90

420-450

570-720

26

SM570 Specification:

Thickness: 5mm to 500mm;
Width: 1500mm to 4500mm:
Length: 3000mm to 12000mm
We can supply any size based on customer's requirements
SM570 Adopt standard: JIS G3106 Standard Specification is for Rolled Steels for Welded Structure
Third Party Inspection for SM570: ABS, DNV, BV, GL, CCS, LR, RINA, KR, NK, CE, SGS, IKE, IEI or other quality department.

JIS G3106 SM570 steel Plate Additional Condition

UT(Ultrasonic examination),AR(As Hot Rolled only),TMCP(Thermal Mechanical Control Processing), N(Normalized), Q+T(Quenched and Tempered),Z Direction Test(Z15,Z25,Z35),Charpy V-Notch Impact Test, The Third Party Test(such as SGS Test),Coated or Shot Blasting and Painting.

We are a trusted and reliable brand for our high quality and good manufacturing of SM570 Steel Plate. Our company has been a manufacturer and exporter of JIS G3106 SM570 for decades, and has been sold all over the world with favorable price. As a responsible enterprise, we always stick to be your satisfying partner.
