JIS G3115 SPV235 pressure vessel steel Additional services
SPV235 Grade has a good weldable and used in high temperature equipment and pressure vessel.
|
Grades |
C max |
Si max |
Mn. max |
P max |
S max |
N max |
AL min |
Cr max |
Cu max |
Mo max |
Ni max |
Nb max |
Ti max |
V max |
|
SPV 235 |
0.16 |
0.35 |
0.60-1.20 |
0.025 |
0.015 |
0.012 |
0.02 |
0.3 |
0.03 |
0.08 |
0.3 |
0.02 |
0.03 |
0.02 |
|
Thickness (mm) |
|||
|
SPV235 |
≥6 ≤ 50 |
> 50 ≤ 100 |
> 100 |
|
Yield strength (≥Mpa) |
235 |
215 |
195 |
|
Tensile strength (Mpa) |
400-510 |
||
SPV235 Use:
SPV235 pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, spherical tank, YouQiGuan, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe, spiral case and other equipment and components.
SPV235 Additional services:
UT (Ultrasonic examination),
AR(As Hot Rolled only),
TMCP(Thermal Mechanical Control Processing),
N(Normalized),
Q+T(Quenched and Tempered),
Z Direction Test(Z15,Z25,Z35) ,
Charpy V-Notch Impact Test,HIC test,
NDT ,
PWHT( Simulated Post Weld Heat Treatment),
NACE0175,
The Third Party Test (Such as SGS Test),
Coated or Shot Blasting and Painting.
