LR DH32 Shipbuilding Steel Plate Manufacturer and supplier
Higher-strength LR shipbuilding steel DH32 comes in 12 grades of 3 strengths, DH32 is one of the grades. LRGradeDH32steelplatesare mainly usedin building decks of ships, vessels and boats, other normal repairing works in shipyards.
LR DH32 Shipbuilding Steel Chemical Composition
Grade |
ChemicalComposition(%) |
|
||||||
|
|
C≤ |
Mn |
Si≤ |
P≤ |
S≤ |
Al(cid)≥ |
Cu≤ |
Mark |
|
LRDH32 |
0.18 |
0.90-1.60 |
0.50 |
0.035 |
0.035 |
0.015 |
0.35 |
LR/DH32 |
LR DH32 Shipbuilding Steel Mechanical Property
LR Grade DH32 shipbuilding steel plate |
|||||||
|
Grade |
|
Mechanical Property |
Charpy V Impact Test |
||||
|
Thickness |
Yield |
Tensile |
Elongation |
Degree |
Energy 1 |
Energy 2 |
|
|
LR-DH32 |
mm |
Min Mpa |
Mpa |
Min % |
-20 |
J |
J |
|
t≤50 |
315 |
440-590 |
22% |
20 |
31 |
||
|
50＜t≤70 |
315 |
440-590 |
22% |
26 |
38 |
||
|
70＜t≤100 |
315 |
440-590 |
22% |
31 |
46 |
||
|
Note: Energy 1 is transverse impact test, Energy 2 is longitudinal |
|||||||
1.Honest
2.Have a good knowledge of our corporate and product
3.Say things in concerning and self-condemning attitude
4.Familiar about the market
5, Skills of making deals
6, Rich experience in export business.
7,Well after sales service.
8, Flexiblepolicy!
We are a trusted and reliable brand for our high quality and good manufacturing of LR shipbuilding steel DH32.Our company has been a manufacturer and exporter of LRGradeDH32steelplates for decades, and has been sold all over the world with favorable price. As a responsible enterprise, we always stick to be your satisfying partner.
