LR EH32 Shipbuilding Steel Plate Equivalent Steel Grade
LR EH32 with good toughness properties, higher strength. LR EH32 are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.
LR EH32 Shipbuilding Steel Chemical Composition
Element |
LR EH32Max % |
Element |
LR EH32max % |
|
C |
0.18 |
Ni |
0.40 |
|
Mn |
0.90-1.60 |
Mo |
0.08 |
|
Si |
0.50 |
Al |
0.015 min |
|
S |
0.035 |
Nb |
0.20-0.05 |
|
P |
0.035 |
V |
0.03-0.10 |
|
Cu |
0.35 |
Ti |
0.02 |
|
Cr |
0.20 |
N |
|
LR EH32 Shipbuilding Steel Mechanical Property
Grade |
Thickness(mm) |
Min Yield (Mpa) |
Tensile(MPa) |
Elongation(%) |
Min Impact Energy |
|
|
EH32 |
8mm-50mm |
Min 315Mpa |
440-590Mpa |
22% |
-40 |
34J |
|
51mm-70mm |
Min 315Mpa |
440-590Mpa |
22% |
-40 |
38J |
|
|
71mm-100mm |
Min 315Mpa |
440-590Mpa |
22% |
-40 |
46J |
|
|
The min impact energy is longitudinal energy |
||||||
LR EH32 Equivalent Steel Grade
Equivalent steel grade of LR/EH32 |
|||||||
|
DNV |
GL |
ABS |
BV |
CCS |
NK |
KR |
RINA |
|
NV E32 |
GL-E32 |
AB/EH32 |
BV/EH32 |
CCS/E32 |
K E32 |
R E32 |
RI/E32 |
LR EH32 Shipbuilding Steel Specification
Thickness: 3mm-260mm
Width: 1000mm-4000mm
Length: 3000mm-12000mm
We can supply any size based on customer΄s requirement.
ThedeliveryStatesofLR EH32steelplateisPretreatment, CRorNormalizing.
CR,N,TM,QT(QuenchingandTempering)andotherdeliverystates.
Shipbuilding steel grade, AH32, AH36, DH32, DH36, EH32, EH36, EH40, FH32, EH36 are the high tensile strength steel. If you need AH32, AH36, DH32, DH36, EH32, EH36, EH40, FH32, EH36 shipbuilding steel plates/sheet/bar or chemical composition, mechanical property, and yield strength, please contact us, we will try our best to help you.
