ASTM A387 Grade 22 Class 2,Alloy Steel A387 Grade 22 Plate
ASTM A387 Gr 22 CL 2 is a chromium molybdenum alloy steel plate intended primarily for welded boiler and pressure vessels designed of elevated temperature service.As well as supplying in plate form, we can cut plates to size and also cut to specific shapes.
ASTM A387 Grade 22 Class 2 Equivalents
| BS | EN | ASTM/ASME | DIN |
| 622-515B | 10 CRMO910 | A387-22-2 | 10 CRMO910 |
A387 Grade 22 plates come in thicknesses of between 8 and 40mm and in standard plates sizes of 2m x 12m and 3m x 12m
A387 GRADE 22 PLATES EX-STOCK
- Thickness: 8 – 40 mm
- Width: Up to 3 metres wide
- Length: Up to 12 metres long
- Certification: EN 10204 3.1
A387 Grade 22 Class 2 steel Chemical requirement in Product analysis
|
C % |
Mn % |
P % |
S % |
SI % |
Cr % |
Mo % |
|
0.04-0.15 |
0.30-0.60 |
0.035 |
0.035 |
0.50 |
1.88-2.62 |
0.85-1.15 |
|
Ni % |
V % |
Nb % |
B % |
Nitrogen |
AL % |
Tungsten |
|
|
|
|
|
|
|
|
we are a large steel supplier and exporter in China,cooperated with Chinese big steel mills to export high quality and super thickness steel plate. For the competitive price in A387 Grade 9 Class 2, please contact us by email.
