SA202 grade B steel,SA202 grade B steel chemical composition
ASME SA202 Grade B(SA202GRB) Pressure Vessel And Boiler Steel Plate are used in Pressure Vessel,Boiler,Storage Tanks and Heat Exchanger in Oil,Gas Project.we specializes in the above steel plates comply with ASME SA202/SA202M, ASME SA20/SA20M. We are assure of supplying SA202Gr.B in superior quality.
SA202 Grade B Chemical Composition
Chemical Composition and Mechanical Property:
|
Grade |
Chemical Composition(%) |
||||
|
C |
Mn≥ |
Si |
P |
S |
|
|
SA202 Grade B
SA202GR B)
|
0.25 |
0.97-1.52 |
0.54-0.96 |
0.035 |
0.035 |
|
Grade |
Mechanical Property |
|
|||
|
Tensile Strength(MPa) |
Yield Strength(MPa) |
% Elongation in 2 in.(50mm) min |
Impacting Test Temperature(°C) |
|
|
|
SA202 Grade B
SA202GR B)
|
585-760 |
325 |
18 |
-20,40,-60 |
|
SA202 Grade B Mechanical Property
| Grade | SA202 Grade B Mechanical Property | |||
| Thickness | Yield | Tensile | Elongation | |
| SA202 Grade B | mm | Min Mpa | Mpa | Min % |
| 6-50 | 325 | 587-760 | 18% | |
| 50-100 | 325 | 587-760 | 15% | |
Equivalent steel grade of SA202 Grade B
| Equivalent steel grade of SA202 Grade B | |||||||
| Europe | Belgium | Germany | France | Italy | Sweden | India | Japan |
| E St E315 | 18 MD 4.05 | 16 Mo 6 | 22.16.04 | 450M | |||
Shanghai katalor is the most competitive manufacture and supplier of ASME SA202/ SA202M Grade B Pressure Vessel Steel Plate in China. For more details, please contact us by email or chat with our liveperson,we will give you the best service and low price!
