ASTM A240 Grade 310S Stainless Steel Main Material Property List

Posted:2017-01-14 00:37:05

ASTM A240 Grade 310S Stainless Steel Main Material Property List

Alloy 310 is an austenitic stainless steel that combines excellent high temperature properties with good ductility and weld ability. Grade 310S Stainless Steel is mainly used in Furnace Parts, Oil Burner Parts, Heat Exchangers, Welding Filler Wire and Electrodes, Annealing Covers, Combustion Tubes, Fire Box Sheets.

Chemical composition % of grade 310 and 310S stainless steel


Chemical Composition

310

310S

Carbon

0.25 max

0.08 max

Manganese

2.00 max

2.00 max

Silicon

1.50 max

1.50 max

Phosphorus

0.045 max

0.045 max

Sulphur

0.030 max

0.030 max

Chromium

24.00 - 26.00

24.00 - 26.00

Nickel

19.00 - 22.00

19.00 - 22.00

Mechanical properties of of grade 310/310S stainless steel


Mechanical Properties

310/ 310S

Grade 0.2 % Proof Stress MPa (min)

205

Tensile Strength MPa (min)

520

Elongation % (min)

40

Hardness (HV) (max)

225

Machinability of ASTM A240 Grade 310S

310S Stainless Steel chips are stringy and it will work harden rapidly. It is necessary to keep the tool cutting at all times and use chip breakers.
