P235GH EN10028 standard steel plate

Posted:2016-11-07 04:32:23

P235GH EN10028 standard steel plate

P235GH is EN10028 standard pressure vessel steel, with a minimum yield strength of 235 Mpa, suitable for high temperature environment, the rolling can be heat treatment. P235GH used for the petrochemical industry and the construction of high-temperature steam equipment, such as boilers, separators, flanges and so on.

P235GH Chemical composition:

Element

% by mass

Element

% by mass

Carbon (C)

≤0.16

Silicon (Si)

≤0.35

Manganese (Mn)

0.60 to 1.20

Phosphorous (P) (max)

0.025

Sulphur (S) (max)

0.015

Aluminium (Al)

≤0.020

Nitrogen (N)

≤0.012

Chromium (Cr)

≤0.30

Copper (Cu)

≤0.30

Molybdenum (Mo)

≤0.08

Niobium (Nb)

≤0.020

Nickel (Ni)

≤0.30

Titanium (Ti) (max)

0.03

Vanadium (Vi)

≤0.02

P235GH Physical properties:

Grade

Type

Thickness
(mm)

Yield Strength
MPa (min)

Tensile Strength
MPa

Elongation
% (min)

Impact Energy
(KV J) (min)

-20°

+20°

P235GH

Normalized

≤ 16
16> to ≤40
40> to ≤60
60> to ≤100
100> to ≤150
150> to ≤250

235
225
215
200
185
170

360 to 480
360 to 480
360 to 480
360 to 480
350 to 480
350 to 480

24
24
24
24
24
24

27
27
27
27
27
27

34
34
34
34
34
34

40
40
40
40
40
40

P235GH Steel Plate Dimension:
Thickness: 3mm-300mm
Width: 1500mm-3500mm
Length: 3000mm-12000mm

Katalor specializes in the production of steel products for many years, with excellent team and sophisticated equipment to serve the vast number of overseas customers, and customers get the praise, if you are interested in P235GH, please contact us.
