Chrome Molybdenum AlloySA 387 Gr 11 Cl 2 Pressure Vessel and Boiler Steel Price
Pressure vessel steel plate SA387 Grade 11 CL 1 and SA387 Grade 11 CL 2 are in American standard ASME SA 387/SA 387M.SA 387 Gr 11 Cl 2plates are widely used in the fabrication of boilers and pressure vessels in industries such as shipbuilding, petrochemical and manufacturing.
Key Words: ASME SA387 Grade 11 Class2 (SA387GR11CL2) Storage Tanks Steel plate. ASME SA387 Grade 11 Class2 (SA387GR11CL2) Heat Exchanger Steel Plate.
SA 387 Gr 11 Cl 2 Chemical Composition and Mechanical Property:
|
Grade |
Chemical Composition (%) |
||||
|
C |
Mn≥ |
Si |
P |
S |
|
|
SA387 Grade 11 Class2(SA387GR11CL2) |
0.04-0.17 |
0.35-0.73 |
0.44-0.86 |
0.035 |
0.035 |
|
Grade |
Mechanical Property |
|
|||
|
Tensile Strength(MPa) |
Yield Strength(MPa) |
% Elongation in 2 in.(50mm) min |
Impacting Test Temperature(°C) |
|
|
|
SA387 Grade 11 Class2(SA387GR11CL2) |
0.35-0.73 |
310 |
22 |
-20,40,-60 |
|
Delivery Condition of Gr 11 Cl 2 Pressure Vessel Steel
AR(As Hot Rolled), N(Normalized), T(Tempered), Q(Quenched), TMCP, Q+T(Quenched and Tempered), UT(Ultrasonic Test: ASTM A435,ASTM A578-C/B/A,EN10160-S0E1,S1E2,S2E3,S3E4), Impact Test, PWHT(Post Weld Heat Treatment), HIC, Z Test(Z15, Z25, Z35)
SA387Gr11cl2 Pressure vessel steel plate Specification:
Standard: BSEN10082-5
Place of Origin: Shanghai, China (Mainland)
Thickness :1.5 mm -300mm
Width :1000mm-4000mm
Length :1000mm-12000mm
We can supply any size based on customer's requirements
Delivery Time: 30-40days
Payment Item: 30% TT, or LC and TT.
Heat Treatment: Hot Rolled, CR, Normalized, Quenched, Tempering, TMCP, Technology, etc.
Your requirements are our yardstick for success. KATALOR's service has already spread many countries in Europe, America, Southeast Asia, Middle East, South America, Africa, and so on. Our aim is to provide high quality products and outstanding service. Contact our SA 387 Gr 11 Cl 2 Pressure Vessel and Boiler Steel sales team freely if you have any needs.
