GB/T 713 15CrMoR Pressure Vessel and Boiler Steel Plate permissible deviation

Posted:2017-02-23 22:35:34

GB/T 713 15CrMoR Pressure Vessel and Boiler Steel Plate permissible deviation

The standard ofGB 713 is applicabletothe boiler and its accessories and the pressure parts of normal pressure vessel for 3 mm thickness steel plates. GB 713 15CrMoR are also mainly used to build boilers and pressure vessels such as petroleum, chemical industry, power plants.

Keyword: 15CrMoR datasheet, 15CrMoR mechanical properties, chemical element 15CrMoR, technical specifications of 15CrMoR steel material properties. 15CrMoR performance specifications.

Mechanical property for 15CrMoR Pressure vessel steel:


Thickness (mm)

15CrMoR

> 6 ≤ 60

> 60 ≤ 100

>100

Yield strength (≥Mpa)

295

275

255

Tensile strength (Mpa)

450-590

440-580

Chemical composition for 15CrMoR Pressure vessel steel (Heat Analysis Max%)


Main chemical elements composition of 15CrMoR

C

Si

Mn

P

S

Cr

Mo

0.12-0.18

0.15-0.40

0.40-0.70

0.025

0.010

0.80-1.20

0.45-0.60

Key Points ofGB/T 713 15CrMoR

1, Standard:GB 713 Standards.
2, Specifications (T*W*L):3--200mm * 1200--3400mm * 3000--12000mm
We can supply any size based on customer's requirements
3, Delivery Condition: Plates are normally supplied in the tempered or normalized condition.
4, Teat:Z Direction of Tensile Test (Z15, Z25 or Z35), Surface Condition Test, Charpy V-Notch Impact Test, Drop Weight Test, High Temperature Tension Test, Ultrasonic Examination (GB/T 2970 or A435 or A578 or EN10160).
5, Surface Treatment: Shot blasting and painting or coated

Additional technical services for 15CrMoR boiler steel plate

Treatment(Normalized, TMCP, Quenched and Tempered, N+T),Z-test (Z15,Z25,Z35),Ultrasonic Examination, Low temperature impacting test, DWTT, PWHT and cutting & welding into special pieces for end users. Mill test certificate issued under EN 10204 format.

Shanghai Katalor Enterprises Co., Ltd is specialized in supplying GB/T 713 15CrMoR Pressure Vessel and Boiler Steel Plate. Besides that, Shanghai Katalor Enterprises Co., Ltd is also a manufacture, so we could promise the delivery time and the competitive price compared with other company. We sincerely hope new and regular customers come to visit our mill and inquiry GB/T 713 15CrMoR from Katalor.
