JISG3106 SM490YA/B steel

JISG3106 SM490YA/B steel

JISG3106 SM490YA/B steel applies to Bridges, ships, vehicles, oil storage tank, vessel and other structures with good welding properties of hot rolled steel.

SM490YA/B material chemical composition,max

Grade C Si Mn P S
SM490YA/B thick≤100mm 0.20 0.55 1.60 0.035 0.035

SM490YA/B steel mechanical properties

Grade Yield strength,N/mm2 Tensile strength,N/mm2 Elongation
Thickness mm
≤16 >16-40 >40-75 >75-100 >100-160 >160-200 ≤100 >100-200 %
SM490YA/B ≥365 ≥355 ≥335 ≥325 - - 490-610 - ≤5 >5-16 >16-50 ≥19 ≥15 ≥19

JISG3106 SM490YA/B steel specification:

Thickness:5-400mm

Width:1500-4000mm

Length:3000-12000mm

Katalor enterprises as the professional JISG3106 SM490YA/B steel supplier,distributor,manufacturer,we have many JISG3106 SM490YA/B steel in stock,if you need JISG3106 SM490YA/B steel,JISG3106 SM490YA/B steel deep processing,and want to know the price of JISG3106 SM490YA/B steel,welcome to contact us!
